Production possibilities

Modern production company Pacific Microelectronics Inc. (Taiwan) produces printed circuit boards in accordance with standard IPC 6012.

The table shows the key features that are provided by the company. The data on printed circuit boards, on materials and technologies used for their production.

Number of layers	one-layers
	two-layers
	multilayer printed circuit boards from 4 to 28 layers
Materials	FR-2, FR-4, CEM-1, FR-4 High TG, PI, PTFE, PPO, Rogers, Taconic etc.
The width of the conductor	minimum 0.1 mm
The distance between adjacent tracks	minimum 0.1 mm
The distance between adjacent elements of the printed circuit	minimum 0.1 mm
The diameter of the vias	minimum 0.1 mm
Standard thickness of the copper foil	18 microns
	35 microns
Coverage	hot tin HAL thickness of 15 ~ 20 mm
	Immersion Ni-Au plating thickness of 5 m (Ni) + 0.1 m (Au)
	electroplated Ni-Au plating thickness of 5 m (Ni) + 1 microns (Au)
	immersion tin
	carboxylic paste application
	gilding slats
Mask	liquid fotoproyavlyaemaya different colors (green, blue, red, yellow, black, etc.).
Backlash mask Playground	0,1 mm
The thickness of the screen printing line	minimum 0.1 mm
Processing PCB contour	milling
	scribing
	stamp
Precision processing circuit	- 0,1mm
Possible thickness of FR4 material	0,3 mm
	0,5 mm
	0,8 mm
	1,0 mm - standard
	1,5 mm - standard
	1,6 mm - standard
	2,0 mm
The maximum workpiece size	for single-sided and double-sided printed circuit boards 550 mm x 550 mm
	for multilayer printed circuit board of 460 mm x 508 mm
Quality control	electric control adapter (adapter e-test)
	electric control a flying probe (flying probe e-test)
	optical inspection (A.O.I.)
The received file format	PCAD 4.5, P CAD 8; ACCEL EDA, P CAD 200X, PROTEL, ORCAD, EAGLE, DEP7, CAM350, CAMTASTIC, Gerber files.
Additional features production	Production of multi-layer printed circuit board with blind and hidden vias
	Production of printed circuit boards with metal base
	Production of printed circuit boards of high-frequency, high-temperature materials
	Production of flexible printed circuit boards

The company Pacific Microelectronics Inc is one of the largest production companies for the production of printed circuit boards and electronic modules in Southeast Asia. Monthly production is available on more than 6 million square decimeters PP. Installation machines have a capacity of more than 1.5 million components hourly. We use automatic installers DIP-components and advanced soldering equipment of the highest quality. Production capacity of Pacific Microelectronics allow to produce printed circuit boards in the high-frequency and high-temperature materials, such as the FR-2, FR-4, CEM-1, FR-4 High TG, PI, PTFE, PPO, Rogers, Taconic. We produce flex-rigid and flexible printed circuit boards, produce boards on metal substrates, multilayer boards with hidden and blind vias. Production capacities of the company allow standard fabrication and manufacture of extended type. In the main company produced standard products. Specialized products are manufactured in certain production areas. Our company takes orders for the production of printed circuit boards and electronic products on the documentation provided by the customer. One-sided printed circuit board can have a maximum size of 550h550 mm, double-sided and multilayer boards - 460x508 mm. Cooperating with producers and warehouses of electronic components directly, we can carry out a complete set of components in the shortest possible time. Advantages of ordering of printed circuit boards at Pacific Microelectronics: Consistently high quality printed circuit boards manufactured in a single production. Compliance with terms of manufacturing and delivery. Strict adherence to all technological requirements, control of the production process. Confidentiality.

The company Pacific Microelectronics Inc is one of the largest production companies for the production of printed circuit boards and electronic modules in Southeast Asia. Monthly production is available on more than 6 million square decimeters PP. Installation machines have a capacity of more than 1.5 million components hourly. We use automatic installers DIP-components and advanced soldering equipment of the highest quality.

Production capacity of Pacific Microelectronics allow to produce printed circuit boards in the high-frequency and high-temperature materials, such as the FR-2, FR-4, CEM-1, FR-4 High TG, PI, PTFE, PPO, Rogers, Taconic. We produce flex-rigid and flexible printed circuit boards, produce boards on metal substrates, multilayer boards with hidden and blind vias.

Production capacities of the company allow standard fabrication and manufacture of extended type. In the main company produced standard products. Specialized products are manufactured in certain production areas. Our company takes orders for the production of printed circuit boards and electronic products on the documentation provided by the customer.

One-sided printed circuit board can have a maximum size of 550h550 mm, double-sided and multilayer boards - 460x508 mm.

Cooperating with producers and warehouses of electronic components directly, we can carry out a complete set of components in the shortest possible time.

Advantages of ordering of printed circuit boards at Pacific Microelectronics:

Consistently high quality printed circuit boards manufactured in a single production.
Compliance with terms of manufacturing and delivery.
Strict adherence to all technological requirements, control of the production process.
Confidentiality.
